SS
|
7mm height |
6.3 to 63 |
0.1 to 330 |
-40℃~85℃ |
1,000 |
|
SS-H
|
7mm height, High Temperature |
6.3 to 63 |
0.1 to 330 |
-40℃~105℃ |
1,000 |
|
SB
|
5mm height |
4 to 50 |
0.1 to 470 |
-40℃~85℃ |
1,000 |
|
SB-H
|
5mm height, High Temperature |
4 to 50 |
0.1 to 470 |
-40℃~105℃ |
1,000 |
|
SF
|
7mm height |
6.3 to 63 |
0.1 to 220 |
-40℃~105℃ |
2,000 |
|
ND
|
Non-Polar Standard |
6.3 to 250 |
0.47 to 2,200 |
-40℃~85℃ |
2,000 |
|
ND-H
|
Non-Polar High Temperature |
6.3 to 250 |
0.47 to 2,200 |
-40℃~105℃ |
1,000 |
|
LB
|
Low Leakage Current |
6.3 to 100 |
0.47 to 4,700 |
-40℃~85℃ |
2,000 |
|
LB-H
|
Low Leakage Current, High Temperature |
6.3 to 100 |
0.47 to 4,700 |
-40℃~105℃ |
1,000 |
|
SM
|
General, Downsize |
6.3 to 450 |
0.1 to 22,000 |
-40℃~85℃ |
2,000 |
|
TW
|
High temperature 125℃, high reliability |
10 to 450 |
4.7 to 1,000 |
-25 to 15℃ |
2,000 |
|
TV
|
High temperature 125℃, long life |
10 to 50 |
22 to 1,000 |
-55 to 125℃ |
3,000 to 5,000 |
|
TD
|
High-temperature 130℃, High reliability. |
10 to 450 |
4.7 to 4,700 |
-40~130°C |
1,000 to 4,000 |
|
TX
|
High-temperature 135℃, High reliability. |
10 to 50 |
22 to 1,000 |
-55~135°C |
1,000 to 2,000 |
|
PW
|
High Ripple Current, Downsize |
200 to 500 |
10 to 470 |
-25℃~105℃ |
2,000 |
|
PV
|
Downsize with high ripple current |
200 to 450 |
6.8 to 470 |
-25℃~105℃ |
2,000 to 5,000 |
|
PJ
|
long life 8,000 to 10,000 hours |
160 to 500 |
6.8 to 330 |
-25℃~105℃ |
8,000 to 10,000 |
|
PJL
|
Downsize, high ripple current, long life |
160 to 450 |
6.8 to 470 |
-40 to 105℃ |
12,000 to 15,000 |
|
MW
|
Low ESR, High ripple current |
200 to 450 |
68 to 470 |
-25℃~105℃ |
2,000 |
|
MV
|
Low ESR, High ripple current , long life |
200 to 450 |
6.8 to 470 |
-25℃~105℃ |
5,000 |
|
MJ
|
Low ESR, Downsize , High ripple current , long life |
200 to 450 |
6.8 to 330 |
-25℃~105℃ |
8,000 to 10,000 |
|
MZ
|
Low ESR, High ripple current , Ultra miniature size |
200 to 450 |
18 to 270 |
-40℃~105℃ |
2000 |
|
MA
|
Low ESR , Long life, Ultra miniature size |
400 to 450 |
33 to 120 |
-25℃~105℃ |
5,000 |
|
MQ
|
Low ESR, High ripple current,, Long life, Ultra miniature size |
200 to 450 |
33 to 220 |
-25℃~105℃ |
10,000 |
|
SW
|
High ripple current, Miniaturized |
160 to 450 |
22 to 680 |
-25℃~105℃ |
2,000 |
|
SQ
|
High ripple current, Long life 5,000 hours |
160 to 450 |
22 to 680 |
-25℃~105℃ |
5,000 |
|
SJ
|
High ripple current, long life 10,000 hours |
160 to 450 |
22 to 680 |
-40 to 105℃ |
10,000 |
|
VW
|
High ripple current, Miniaturized |
160 to 450 |
22 to 680 |
-25℃~105℃ |
2,000 |
|
VQ
|
High ripple current, Long life 5,000 hours |
160 to 450 |
22 to 680 |
-25℃~105℃ |
5,000 |
|
VJ
|
High ripple current, Long life 10,000 hours |
160 to 450 |
22 to 680 |
-25℃~105℃ |
10,000 |
